What is EPDM Material?

Properties, Applications, and Common Questions of Ethylene Propylene Diene Monomer

By Cody David & Juan Ramirez

EPDM material, also known as ethylene propylene diene monomer or EP rubber, is a form of synthetic rubber exhibiting unique characteristics of strong outdoor resistance and robust physical-dynamic properties. These characteristics make it the ideal choice for gasketing, sealing solutions, O-rings, potable water gaskets, grommets, and weather-stripping applications.

Advantages
EPDM is an excellent fit for applications requiring:

  • Weather resistance (heat, ozone, and sunlight)
  • Electrical insulation
  • Durability (high abrasion resistance & non cracking tendencies)
  • High compression set
  • Water resistance

Disadvantages
EPDM is a poor fit for applications requiring:

  • Oil, gas & fuel resistance (petroleum-based products)
  • Resistance to aromatics or solvents

EPDM rubber products come in all shapes and sizes, as demanded by the application. Many industrial and consumer applications rely on EPDM rubber extrusions, rubber molded parts and custom sheet rubber.



1. Understanding EPDM Material Properties

When choosing which material is most suitable for your application, the following charts serve as a basis when considering the use of EPDM. We recommend consulting with a rubber manufacturer and/or material design specialists prior to making this selection. WARCO has developed thousands of rubber compounds, and would be happy to provide guidance.

Table 1: General Physicals of EPDM

Property Value

Durometer Hardness (Shore A)

 30 to 90

Tensile Strength (psi)

 800 to 2600

Elongation at Break (%)

 100 to 900

Compression Set (%)

 10 to 30

Temperature Range (°F)

 -60°F to +300°F

Table 2: EPDM Chemical Resistance Guide

Property Value

Acetone

 Excellent

Fuels

 Poor

Salt Water

 Excellent

Aromatic Hydrocarbons

 Poor

Alcohols

 Good

Animal and Vegetable Oils

 Good

For a comprehensive guide regarding chemical resistances and recommendations for common rubber polymers including EPDM material, see our guide at warco.com/chemical.

Table 3: EPDM Material Characteristics

Category Property Performance

Mechanical

 Abrasion Resistance Excellent
Impact Resistance Very Good
Rebound Rating Very Good
Tear Resistance Fair
Flex Cracking Resistance Very Good

Environmental

 Chemical Resistance Good
Oil Resistance Poor
Weather Resistance Excellent
Ozone Resistance Excellent
Oxidation Resistance Excellent
Sunlight Resistance Outstanding
Application Specific Flame Resistance Poor
Minimum Service Temperatures Good
Maximum Service Temperatures Very Good
Gas Permeability Good
Radiation Resistance Good
Steam Resistance Excellent

For more specific information regarding Ethylene Propylene Diene Monomer rubber products and their characteristics, see our webpage on EPDM at warco.com/epdm. Topics covered include:

  • General Information
  • Physical Properties
  • Environmental Properties
  • Specific Chemical Resistances
  • And many more

2. Applications Suitable for EPDM Rubber

EPDM’s properties make it a suitable choice for a diverse number of applications across various industries, including but not limited to:

  • EPDM Rubber Strips: Used in outdoor applications for sealing and protecting against weather conditions.
  • EPDM Automotive Parts (valves & seals): Commonly utilized in automotive engines and components for durability and resistance to heat and wear.
  • EPDM Electrical Insulation: Serves as an insulating layer in electrical components due to its strong electrical resistance properties.
  • EPDM Tubing/Cord for Window & Door Seals: Offers effective sealing against moisture, air, and dust in construction and household applications.
  • EPDM Gasket Material: Used in industrial machinery to prevent leakage and provide a durable seal in dynamic environments.
  • EPDM Vibration Dampening Padding: Reduces vibration and noise in industrial machinery and equipment.
  • EPDM Roofing Rolls: Commonly used in roofing for its weather resistance and durability against sunlight and ozone.

EPDM is a comparatively cost-effective material, making it the ideal elastomer for high volume applications that require its uniquely high-performance characteristics.



3. WARCO’s Pre-Formulated EPDM Rubber Products

While we have a vast array of EPDM products designed for a specific application & customer, we also offer a selection of pre-formulated rubber products that have been developed for EPDM applications that WARCO regularly services.

Many of these products are available as sheet rubber, heavy gauge slab rubber, extruded rubber or custom molded rubber. Click on each product to learn more.

EPDM Product Primary Feature

PURE™: NSF/ANSI/CAN 61 Certified Rubber

 Certified to NSF/ANSI/CAN 61 & 372

Peroxide Cure EPDM

 Exceptional heat and aging stability

EPDM MIL-R-21252 / MIL-DTL-21252

 Meets the MIL-R-21252 / MIL-DTL-21252 specification

EPDM MIL-R-900

 Meets the MIL-R-900 specification

EPDM MIL-R-83285 / SAE-AMS-R-83285

 Meets the MIL-R-83285 / SAE-AMS-R-83285 specification

EPDM ASTM D2000 M4AA

 Meets the ASTM D2000 M4AA specification

Commercial EPDM

 Excellent ozone, oxidants, and weather resistance

4. Common Questions About EPDM

Throughout our extensive 115-year history of formulating and manufacturing rubber products for a wide range of applications, we have compiled a list of commonly encountered questions pertaining to EPDM. If you have any additional questions regarding rubber applications, please contact us at sales@warco.com or 714-532-3355.

Q1: What is EPDM generally attacked by?
EPDM is generally attacked by mineral oils, solvents, and aromatic hydrocarbons. See a more extensive list at warco.com/chemical.

Q2: What is EPDM generally resistant to?
EPDM is generally resistant to animal and vegetable oils, ozone, strong and oxidizing chemicals. See a more extensive list at warco.com/chemical.

Q3: What is the shelf life of EPDM?
EPDM has a shelf life of 5 to 15 years when stored in a cool, dry place below temperatures of 75°F and away from direct sunlight or open flames.
See Rubber Storage Conditions for more information on how to properly store your rubber products.

Q4: How does EPDM rubber compare to SBR rubber?

Depending on availability, both polymers can service similar applications. However, EPDM tends to have better physical properties with lower comparative amount of polymer content in the formulations. Depending on the application requirements and polymer availability, you can get better physical properties than SBR at similar costs.

Q5. What is the difference between sulfur cured EPDM and peroxide cured EPDM?

While there are a number of differences between these two rubber product types, the primary distinction is in high temperature resistance. Peroxide cured EPDM can resist temperatures up to +300°F, while sulfur cured EPDM will generally be rated up to +250°F maximum.

Q6. What does EPDM stand for?
EPDM or EP rubber stands for Ethylene Propylene Diene Monomer.
