Close Up of Black Extruded Rubber Cable Jacket with Protected Inner Wires

Product Description

Neoprene Cable Jacket Tubing to MIL-R-6855 / MIL-PRF-6855

Neoprene Cable Jacket Tubing to Mil-R-6855 / MIL-PRF-6855 protects wires and cables from abrasion, corrosion and the elements. Designed to fit loose or be blown on to wire bundles for a tight fit. WARCO carries compound in stock for a shorter production lead time.

MIL-R-6855 Class 2 is equivalent to MIL-PRF-6855 Class 2. Made in the USA.

Color: Black

Samples available upon request.

Key Aspects

Temperature Range:-67°F to +220°F
Durometer (Shore A ± 5):60
Tensile (min.):1500 psi
Elongation (min.):300%
Talc:Talc Present
Specifications:MIL-R-6855 Class 2 Type A/B
Compound Number(s)Part Number(s)
060E00550031209361003120936600312093710031209374
0031209376003120937800312093800031209381
0031209383003120938500312094000031209403
0031209404003120940500312094060031209407
0031209408003120940900312094110031209412
0031209413003120941400312094150031209419
0031209423003120942400312094260031209427
0031209435003120944100312094470031209448
0031209450003120946300312094710031209472
0031209628003120963800312096620031209684
0031209687003120969000312097390031209740
0031209753003120975400312097900031209793
0031209795003120980300312098270031210502
0031210554003121062000312106970031210761
0031210786003121080700312109010031210903
0031211169003121125300312113320031211395
0031211419003121142000312114210031211594
0031211610003121185700312120450031212046
0031212152003121217000312121860031212279
0031212319003121236100312124390031212516
0031212791003121305900312131040031213159
0031213258003121328200312134140031213529
0031213540003121357300312138670031213921
0031213983003121414400312142230031214243
0031214993003121500000312154260031215500
0031215559003121557700312157590031215905
0031215986003121610400312164920031216533
0031216819003121682000312169760031217576
0031217797003121838900312188270031218912
0031236711003123744700312375940031238487
0031238488003123889000312391170031240701
0031240745003124148800312414920031252526
0031252536003125258900312526310031252637
0031252688003125280200312530400031253146
0031253400003125360900312543430031254344
0031254560003125480100312548250031255435
0031255712003125602400312586890031258746
0031258853003125926600312593990031259553
0031259834003126002400312604070031260441
0031260443003126057100312616260031261627
0031261628003126162900312617950031261796
0031261797003126179800312617990031261800
0031261801003126180200312618030031261804
0031261805003126180600312618080031261809
0031261810003126181100312618120031261813
0031261814003126181500312618160031261817
0031261818003126181900312618200031261821
0031261822003126182300312618240031261825
0031261826003126182800312618290031261830
0031261831003126183300312618340031261835
0031261836003126183800312618390031261840
0031261841003126184200312618430031261844
0031261845003126184600312618520031261853
0031261854003126185500312618560031261857
0031261858003126185900312618600031261861
0031261862003126186300312618640031261865
0031261866003126186700312618680031261869
0031261871003126187200312618730031261874
0031261875003126187600312618770031261878
0031261879003126188000312618810031261882
0031261883003126188400312618870031261888
0031261889003126189000312618910031261892
0031261893003126189400312618950031261896
0031261897003126189800312618990031261900
0031261901003126190200312619030031261905
0031261906003126190700312619080031261909
0031261910003126191100312619120031261913
0031261914003126191500312619160031261917
0031261918003126191900312619200031261921
0031261922003126192300312629530031263082

We comply with the Buy American Act requirements.

Advanced Technical Details

Durometer
Hardness
(Shore A ± 5)
Inner Diameter
(inches)
Wall Thickness
(inches)
Tensile
(min.)
Ultimate
Elongation
(min.)
Temperature
Range
SpecificationsSpecification
Sheet
60
060E0055
1/16 – 51/32 – 11500 psi300 %-50°F to +220°FMIL-R-6855 / MIL-PRF-6855 Class 2 Type A/B Grade 60

Compound Number: 060E0055(60E55)

Unsure on how to read our compound number? Read the page, “How to Read a Compound Number”.

In addition to the previously mentioned specification, we also offer a comprehensive list of tables and explanations relating to the MIL-PRF-6855 specifications for rubber sheet, rubber strips, rubber extruded tubing, and rubber extruded u channels. Learn more at this link.

Our rubber products are a proprietary blend of various polymers formulated to meet stated physicals and specifications. The named product polymer is not necessarily the primary polymer representing the highest percentage of the polymer blend. Determination of the suitability of the goods for the uses and applications contemplated by Buyer and others shall be the sole responsibility of the Buyer or user. No guaranty is given with respect to length of service on any particular application. Suggestions or recommendations made by Seller in its product literature concerning uses or applications of the goods are believed to be reliable, but Seller makes no warranty or guaranty of results to be obtained since the conditions of the use and application by Buyer and others are beyond Seller’s control. The specification listed here, MIL, represents the United States Military Departments and the Defense Agencies’ standardization documents that have been developed and used for products, materials, and processes that have multiple applications to promote commonality and interoperability and to limit the variety of items in the military supply system. Their website can be found here: https://www.dsp.dla.mil/Specs-Standards/.

View complete Terms & Conditions of Sale for suitability of use and formulations

Other Rubber Tubing Products

60 Durometer Neoprene Tubing

  • Durometer: 60
  • Temperature Range: -50°F to +220°F
  • Spec: Anti-Fungal Per MIL-STD-8.10 ASTM G21 MIL-STD-454 MIL-R-6855
